Solution

Switchboards · Racks · PDUs · Industrial Plugs · Power Cords | Built for AI/HPC Density

The Problem with Fragmented Procurement

Five suppliers across three countries. Mismatched interfaces. Inconsistent lead times. On-site rework. This is how data center projects fall behind schedule and over budget.

ANEN Power delivers the full power chain — main switchboard → row cabinet → rack → PDU → industrial plug → power cord. One vendor. One standard. One BOM. From primary distribution to rack-level connection, all integrated.

The Complete Product Chain: Every Link Verified

① Switchboards / Distribution Cabinets

• Main input 800A–4000A, 415Y/240V, 3P+N+PE
• 100% full-capacity neutral bus, designed for nonlinear IT loads
• IEC/EN 61439 design verification: short-circuit, temperature rise, protective conductor
• Integrated multifunction meter (Modbus TCP/SNMP/Redfish)
• Full-capacity neutral bus + separate equipment-ground bus, clearly labeled

② Racks

• Standard 19-inch, compatible with 42U/48U/52U cabinets
• High-density structural design, supports 30–150kW per rack
• Front/rear service access, ample cable management space
• Fully compatible with 0U vertical PDU mounting

③ Smart PDUs

• 18/24/36/42/48/60-outlet C39 combination outlets, accepts C13/C15/C19/C21
• 32A/63A/125A three-phase input, built for GPU/AI high-density racks
• Outlet-level metering + remote switching
• PDU input and phase-level (L1/L2/L3) metering
• Local LCD display for real-time voltage, current, power
• Communications: HTTP/HTTPS, SNMP, Modbus TCP, Redfish API
• 0U vertical mount, total length ≤2000mm, fits 42U/48U/52U cabinets
• Full load at 40°C ambient, derating curve above 40°C provided

④ Industrial Plugs / Receptacles

• IEC 60309 standard, 125A, 415V, 5-pin (3P+N+PE), 6h
• IP67 rated, dust and water resistant
• Panel-mounted, factory wired
• Fully matched to switchboard and PDU input

⑤ Power Cords / Cable whips

• Custom lengths: based on practical applications
• High-current rating, compatible with 125A input
• Fully compatible with PDU and switchboard interfaces

Why ANEN Power?

• End-to-end coverage — from primary distribution to rack-level connection
• High-density ready — supports 30–150kW per rack for GPU/AI clusters
• Certified quality — UL / CE, built for Tier III/IV projects
• Fast delivery — 25–35 days bulk lead time, far faster than industry average (20+ weeks)
• Custom engineering — OEM/ODM to your exact specifications
• Full traceability — MEC production tracking from assembly to test
• Proven by industry leaders — long-term OEM partner to EATON, Delta and Huawei; volume deployments verified in North American AI data centers

Applications

• AI training and inference data centers
• Hyperscale cloud data centers
• HPC clusters
• Colocation and wholesale data centers
• Edge computing nodes
• Modular / containerized data centers

Request Catalog & Power Distribution Solution

Whether you are planning a new campus or expanding an existing facility, we deliver the complete solution — from switchboard to rack. One vendor. One standard. One BOM.
